Brava Metro Entrance Knob Set Fire Rated 60mm Keyed Alike EA3000SS60

Brava Metro Entrance Knob Set Fire Rated 60mm Keyed Alike
EA3000SS60

BRAVA Metro EA3000 series commercial grade 60 mm backset entrance knobset.

Successfully tested up to 4 hours (depending on type of doorset) on fire door assemblies in accordance with Australian Standard AS 1905.1- 2005, Part 1: Fire Resistant Doorsets.

Entrance function

• Outside key unlocks outside knob.
• Inside knob free at all times, push button locks outside knob.

Additional info

• Cylindrical fixing.
• Silca LW5 profile 6 pin cylinder.
• Incorporates the popular PD 8221 barrel.
• Compatible with most restricted keying systems.
• Boxed and colour coded.
• 2 keys supplied.
• Fire rated.
• Finished in satin stainless steel.

Specifications:

• Door thickness: 35-45mm
• Backset: 60mm
• Max. Lever / knob projection (distance may not include turnsnib): 69.5mm
• Strike: 70mm x 27mm x 1.2mm
• Latch: 60mm backset
• Latch face plate: 57mm x 25mm
• Cylinder: LW5 profile
• Door handing: Non-handed knobs/levers
• Rose: 75mm
